Salt lake lithium filter-Xinxiang Yinuo Machineries Co., Ltd.

Salt lake lithium filter at the same time both washing, filtration, separation and other functions, small footprint, filtration separation effect is good, at present, the equipment has gone through hundreds of performance tests, fully simulate the process of absorbing lithium ions from brine, lithium ion extraction efficiency can be improved to 3-5 times that of traditional equipment.


Main parameter

Model	Filter area	Drum diameter	Drum Width	Durm rotational speed	Transmission power	External dimension	Machine weight
Model	M2	mm	mm	R/min	kw	(LWH) mm	kg
G2/1	2	1000	700	0.1-2	1.1	1340x1700x1300	960
G5/1.6	5	1600	1040	0.1-2	1.5	1920x2350 x1340	3200
G10/1.85	10	1850	1780	0.1-1.8	2.2	2760x2650x2150	4240
G20/2.35	20	2350	2770	0.1-1.8	3.0	3850x3150x2650	5950
G30/2.64	30	2640	3680	0.1-1.5	4.0	4800x4380x2940	8420
G40/3.17	40	3170	4060	0.1-1.5	5.5	5170x5280x3470	11200
G45/3.17	45	3170	4580	0.1-1.5	5.5	5750x5380x3470	11600
G60/3.43	60	3430	5630	0.1-1.2	7.5	7090x6430 x3730	14800
